TQE ON/OFF Explosion-proof Electric quarter turn actuator for butterfly valve, Motor operated MOV ac
Brand Torq
Power Source AC220/AC110V/AC380V
Appearance color Color optional
Types of control ON/OFF
Turn Around Angle Scope 0~90°
Machine Weight 11kg~55kg
Parameters
Brand
Torq
Power Source
AC220/AC110V/AC380V
Appearance color
Color optional
Types of control
ON/OFF
Turn Around Angle Scope
0~90°
Machine Weight
11kg~55kg
I know
Detail

TQE Explosion-proof Actuator Data

Model

Max Torque

Open/Close Time

Motor

Rated Current( A) 50Hz

Manual Handwheel Turns

Weight

Single Phase

Triple Phase

N.M

S

W

110V

220V

380V

440V

N

Kg

TQE-10

100

16

25

0.82

0.41

0. 25

0. 26

10

11

TQE-15

150

16

40

1.62

0.83

0. 4

0. 26

11

11. 5

TQE-20

200

20

40

1.62

0.83

0. 4

0. 26

11

14

TQE-30

300

26

60

1.96

0.98

0. 45

/

13. 5

19. 5

TQE-40

400

26

90

2.4

1.2

0. 6

/

13. 5

20

TQE-50

500

26

120

2.62

1.31

0. 75

/

13. 5

20. 5

TQE-60

600

43

120

2.62

1.31

0. 75

/

16. 5

32

TQE-100

1000

43

200

3.58

1.79

1. 2

/

16. 5

32. 5

TQE-200

2000

85

200

3.58

1.79

1. 2

/

49. 5

55


TQE Dimensions


TQE- 10 / 15 Profile and Dimensions



TQE- 20 Profile and Dimensions

TQE- 30/40/50 Profile and Dimensions

TQE- 60/100 Profile and Dimensions

TQE- 200 Profile and Dimensions


TQE Model Actuator is designed Explosion-proof, its Electric actuator for quarter turn/part turn valves, such as ball valve, butterfly valve, plug valve, etc. Motor operated,MOV valve Actuator.


For more information, please click download the PDF file:TORQ TQE Multi turn series
